High-throughput Vertical Electrophoresis Cell DYCZ-20H
Specification
|
Dimension (LxWxH) |
408×160×167mm |
|
Gel Size (LxW) |
316×90mm |
|
Comb |
102 wells |
|
Comb Thickness |
1.0mm |
|
Number of Samples |
204 |
|
Buffer Volume |
Upper tank 800ml; lower tank 900ml |
Description
DYCZ-20H consists of main tank body, lid (with power supply lead), buffer tank. Accessories: glass plate, comb,etc.The electrophoresis tank is made by polycarbonate, and it is injection molded at one time, which is high transparency, strength and impact resistance. The sample volume is large, and 204 samples can be tested at a time.The protective cover of the platinum electrode can effectively prevent the platinum wire from being damaged. The upper and lower tanks are equipped with transparent safety covers, and the upper tank safety covers are equipped with heat dissipation holes. With a water-cooling system in place, it can achieve a genuine cooling effect and meet various experimental needs. 99.99% high-purity platinum electrode, the best electrical conductivity, corrosion and aging resistance.
Application
DYCZ-20H electrophoresis cell is used for separating, purifying and preparing charged particles like biological macro molecules - nucleic acids, proteins, polysaccharides, etc. It is suitable for rapid SSR experiments of molecular labeling and other high-throughput protein electrophoresis.
Featured
•The number of samples can ran up to 204 pieces, can use multi-channel pipettes to add samples;
•Adjustable main structure, can do variety experiments;
•Multi-casting gel to make sure gels have strong consistency;
•High quality PMMA, glittering and translucent;
•Save buffer solution.
FAQ
Q: What kind of samples can be analyzed using a high-throughput vertical electrophoresis cell?
A: A high-throughput vertical electrophoresis cell can be used to analyze a variety of biological molecules, including proteins, nucleic acids, and carbohydrates.
Q: How many samples can be processed at once using a high-throughput vertical electrophoresis cell?
A: The number of samples that can be processed at once using a high-throughput vertical electrophoresis cell depends on the specific instrument, but typically it can process anywhere from 10 to hundreds of samples simultaneously. DYCZ-20H can ran up to 204 pieces.
Q: What is the advantage of using a high-throughput vertical electrophoresis cell?
A: The advantage of using a high-throughput vertical electrophoresis cell is that it allows for the efficient processing and analysis of a large number of samples at once, saving time and resources.
Q: How does a high-throughput vertical electrophoresis cell separate molecules?
A: A high-throughput vertical electrophoresis cell separates molecules based on their charge and size. The molecules are loaded onto a gel matrix and subjected to an electric field, which causes them to migrate through the gel matrix at different rates based on their charge and size.
Q: What types of staining and imaging techniques can be used to analyze separated molecules?
A: Various staining and imaging techniques can be used to visualize and analyze separated molecules, including Coomassie Blue staining, silver staining, and Western blotting. Additionally, specialized imaging systems such as fluorescent scanners can be used for detection and analysis.
